The emergency lighting luminaire is equipped with a monitoring module for automatic function and duration tests and easy-NB connectivity to ensure operation in accordance with EN 50172 and IEC 62034. The included additional module offers easy commissioning via a device and operating system-independent web application with a layout that adapts itself to the screen. Easy-NB emergency lighting luminaires can be easily assigned to an object or property using the QR code provided. The connectivity of each easy-NB emergency lighting luminaire takes place exclusively via a secure VPN tunnel via the mobile network to a German data center. All data communication fees are included for a period of 7 years from delivery on and are extended by 7 years at the moment the battery is replaced.
| Viewing distance | 28 m |
| Nominal voltage AC | 230 V AC 50/60 Hz |
| Cell technology | LiFePO4 |
| Autonomy | 8 h |
| Degree of protection | IP65 |
| Protection class | II |
| Ambient temperature | -20 - 40 °C |
| Housing material | Plastic |
| Housing colour | White |
| Mounting | Surface-mounted wall |
| Article data | |
| Item number | HAW883ENB.V2+EBH |
| EAN | 4250600746631 |
| Marking | |
| Luminance of pictogram | > 500 cd |
| Viewing distance | 28 m |
| Type of pictogram | Sticky foil |
| Mounting | |
| Mounting | Surface-mounted wall |
| Housing | |
| Degree of protection | IP65 |
| Protection class | II |
| IK Class | IK08 |
| Housing material | Plastic |
| Housing colour | White |
| Surface-mounted cabling | Yes |
| Illuminant | |
| LED power | 1 W |
| Dimmable | No |
| Mains connection | |
| Nominal voltage AC | 230 V AC 50/60 Hz |
| Power AC | 2.3 W |
| Power DC | 1.2 W |
| Type of supply | dezentral (selbstversorgt) |
| Accumulator | |
| Cell technology | LiFePO4 |
| Nominal voltage | 6.4 V |
| Nominal capacity | 3000 mAh |
| Autonomy | 8 h |
| Dimensions & Weight | |
| Length | 355 mm |
| Width | 135 mm |
| Height | 79 mm |
| Weight | 1.2 kg |
| Packing length | 385 mm |
| Packing width | 145 mm |
| Packing height | 85 mm |
| Shipping weight | 1.6 kg |
